MAIN FEATURES
Seven rail audio grade power supply
Seven low noise voltage regulator
+12V, +8V, +5V for logic
+/- 12V for analog with inductive noise remover
+/- 28V for analog with inductive noise remover (only with P-1000)

DIMENSIONS
425mm W, 110mm H, 360mm D

WEIGHT
20kg

FINISHES
Case: Brushed Aluminium, Black or Silver or Gold
Inserts: Aluminium, Black or Silver or Gold

LINE AND LOAD REGULATION FOR ALL OUTPUTS
0,05 %/V

LINE NOISE REJECTION
>80dB

COMMON MODE NOISE REJECTION
>80dB

POWER
Mains supply: 100/120V & 220/240V with automatic selection; 50/60Hz
Total Power Reserve: 1000W, 1250W (optional)
Power Absorption: 100W
Dynamic Power: >200W
Stand by power: <1W
Full power response time: <2,5usec

ABSOLUTE PHASE CONTROL
selectable from front panel
